KR BV CCS DNV Approved Studlink Anchor Chain

  • 1
  • 2

Brand Name : China Shipping Anchor Chain

Model Number : Studlink Anchor Chain

Certification : KR LR BV NK CCS ABS DNV-GL RMRS IRS RINA

Place of Origin : China

MOQ : 1T

Price : 880~950USD/T

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 22000T/month

Delivery Time : 1~15days

Packaging Details : chains in bundle with steel wire rope nude packing

Size : 22~200mm

Grade : Grade 3

Production : Flash Butt Welded

Material : M1 M2 M3 U1 U2 U3

Pruduce : Studlink Anchor Chain

Surface : Shot Blasting

Standard : ISO 1704

Contact Now

KR BV CCS DNV approved Studlink Anchor Chain



Studlink Anchor Chain are one of the most important tools of the ship for its anchoring operations.



Studlink Anchor Chain are available in various grades from grade 1 up to grade 3. The Stud link Anchor Chain in grade 2 and grade 3 are the most used anchor chains for commercial shipping. The below is Stud link Anchor Chain proof Load and Bearking Load for your reference to help chose the right size and grade of Studlink Anchor Chain.

Type Studlink Anchor Chain
Size 22~162mm
Grade Grade U1 U2 U3 U4
Certificate KR LR BV NK CCS ABS DNV GL RMRS RINA
Production line Flash Butt Welded
Standard ISO 1704
Production capacity 2200T/month
Heat Treatment

normalizing, tempered
Delivery time 1~15days



Also We can offer Install and cleaning a foul hawse service at all chinese port shipyard and in Singapore port, for some famous International Port we have local cooperator to offer one shop service.

China Anchor Chain Factory Fast Delivery,China Shipping anchor chain factory, manufacturer, supplier, China Anchor Chain, Stud Link Anchor Chain Factory Fast Delivery,stockiest,for sales,DNV GL BV ABS LR CCS NK KR Class

Studlink Anchor Chain Date Sheet

KR BV CCS DNV Approved Studlink Anchor Chain

KR BV CCS DNV Approved Studlink Anchor Chain



Dia.(mm) Grade 1 Grade 2 Grade 3
  Breaking Load (kN) Proof Load Breaking Load (kN) Proof Load (kN) Breaking Load (kN) Proof Load (kN)
11 52 36 72 52 102 72
12.5 66 46 92 66 132 92
14 82 58 116 82 165 116
16 107 76 150 107 216 150
17.5 127 89 179 127 256 179
19 150 105 211 150 301 211
20.5 175 123 244 175 349 244
22 200 140 280 200 401 280
24 237 167 332 237 476 332
26 278 194 389 278 556 389
28 321 225 449 321 642 449
30 368 257 514 368 735 514
32 417 291 583 417 833 583
34 468 328 655 468 937 655
36 523 366 732 523 1050 732
38 581 406 812 581 1160 812
40 640 448 895 640 1280 895
42 703 492 981 703 1400 981
44 769 538 1080 769 1540 1080
46 837 585 1170 837 1680 1170
48 908 635 1270 908 1810 1270
50 981 686 1370 981 1960 1370
52 1060 739 1480 1060 2110 1480
54 1140 794 1590 1140 2270 1590
56 1220 851 1710 1220 2430 1710
58 1290 909 1810 1290 2600 1810
60 1380 969 1940 1380 2770 1940
62 1470 1030 2060 1470 2940 2060
64 1560 1100 2190 1560 3130 2190
66 1660 1160 2310 1660 3300 2310
68 1750 1230 2450 1750 3500 2450
70 1840 1290 2580 1840 3690 2580
73 1990 1390 2790 1990 3990 2790
76 2150 1500 3010 2150 4300 3010
78 2260 1580 3160 2260 4500 3160
81 2410 1690 3380 2410 4820 3380
84 2580 1800 3610 2580 5160 3610
87 2750 1920 3850 2750 5500 3850
90 2920 2050 4090 2920 5840 4090
92 3040 2130 4260 3040 6080 4260
95 3230 2260 4510 3230 6440 4510
97 3340 2340 4680 3340 6690 4680
100 3530 2470 4940 3530 7060 4940
102 3660 2560 5120 3660 7320 5120
105 3850 2700 5390 3850 7700 5390
107 3980 2790 5570 3980 7960 5570
111 4250 2970 5940 4250 8480 5940
114 4440 3110 6230 4440 8890 6230
117 4650 3260 6510 4650 9300 6510
120 4850 3400 6810 4850 9720 6810
122 5000 3500 7000 5000 9990 7000
124 5140 3600 7200 5140 10280 7200
127 5350 3750 7490 5350 10710 7490
130 5570 3900 7800 5570 11140 7800
132 5720 4000 8000 5720 11420 8000
137 6080 4260 8510 6080 12160 8510
142 6450 4520 9030 6450 12910 9030
147 6840 4790 9560 6840 13660 9560
152 7220 5050 10100 7220 14430 10100
157 7600 5320 10640 7600 15200 10640
162 7990 5590 11180 7990 15980 11180
